Heavy-Duty Doc & Pin - Single Connection (Adjustable) DP505

Our heavy-duty doc & pin can do it all – from walls to canopies to guardrail loads on balustrades.

You’ll probably select this Doc & Pin option over our DP505 (adjustable series on this site) for any one of the following reasons:

• you're looking to match an existing non-adjustable doc & pin

• you’re certain you don’t want the adjustability features of our DP505

• you have a space constraint between underside of glass to the doc/pin connection – this product offers a closer connection of 49mm [1 15/16”] vs. the DP505’s 76.6mm +/- 6mm [3” +/- ¼”]

When you order from us - you get the complete product.
As you'd expect from us, it’s supplied as a complete package with Doc & Pin fitting, fibre gaskets, ferrule bushings and appropriate structural fasteners cut to fit the thickness of the steel you're mounting to. It even comes with specialized C-spanner tool you need for install (see HERE   for more info).

You'll use this double connection to connect two pieces of glass in the middle of an application (double doc & pin is essentially two single doc and pins mounted back to back through the support structure).

NOTE: Pricing is for part as shown with no modifications.

More about product mount options:

• See all product drawings, technical info and install guides here

• Or a quick guide is below


  • Steel - we offer 3 options for steel thicknesses - 12mm [1/2"], 25mm [1"], 38mm [1 1/2"] - M12 x 50mm Lg. FHCS

  • Glass - Thickness can range from 6-19mm, supplied with 50mm Lg. M2 FHCS
